25.6V 100Ah Lithium Battery
EPEVER’s 25.6V 100Ah Lithium Battery: Utilizing cutting-edge LiFePO4 cells, delivering more than 4000 life cycles, with real-time monitoring functionalities, and comprehensive safety features. Elevate your energy storage with unmatched reliability.
Experience EPEVER's 25.6V 100Ah Lithium Battery: Engineered with cutting-edge LiFePO4 cells, this battery boasts over 4000 life cycles. It suits various applications like solar battery banks, home battery backups, residential solar setups, RV, camping, marine, and emergency power systems.
Stay informed with the LCD screen monitoring SOC, voltage, temperature, and alarms. The battery features cell balance, a durable metal case, and comprehensive protection. Certified by UN38.3, MSDS, IEC62133, IEC62619, and EN IEC61000-6-1/2/3/4, it's hassle-free to install, requires zero maintenance, and supports connecting 2 battery packs in series for expanded capacity.
Get the best value for home battery prices, find top-tier lithium battery manufacturers, and the finest solar battery backup system. Elevate your energy storage capabilities today. Contact EPEVER.
| Model | LFP2.56KWH25.6V-P20L1 |
| Battery Type | LiFeP04 |
| Nominal Voltage (V) | 25.6 |
| Nominal Capacity (AH) | 100 |
| Energy (WH) | 2560 |
| Pack Mode | 8S1P |
| Continuous Discharge Current (A) | 50 |
| Charge Cut-off Voltage (V) | 28.8 |
| Discharge Cut-off Voltage (V) | 20.8 |
| Max.Charge Current (A) | 50 |
| Max.Discharge Current (A) | 100 |
| Peak Discharge Current (A) | 120@10S |
| Recommend Discharge Current (A) | 50 |
| Recommend Discharge Depth (%) | 80 |
| Cycle Life | ≥4000 cycles (25°C,0.5C ) 80％ DOD |
| Communication | —— |
| Display | LCD |
| Charge&Discharge Temperature (°C) | Charge: 0°C~+55°C I Discharge: -20°C~+60°C |
| Optimal Storage Temperature (°C) | 5°C ~ +35°C |
| Recommend Storage Humidity | 20%~80% |
| Terminal | M8 |
| Dimensions (W*H*D) (mm) | 450*180*166 |
| Weight (Kg) | 22±0.5 |
| Transportation | UN38.3, MSDS, IEC62133, IEC62619, EN IEC61000-6-1/2/3/4 |
| IP Class | IP20 |
DATASHEET
EPEVER_DataSheet_LFP2.56KWH25.6V-P20L1
MANUAL
EPEVER_Manual_LFP2.56KWH25.6V-P20L1
Product Highlights
A-grade brand-new prismatic LiFePO4 cells
≥5000 cycles @80% DOD(25℃, 0.5C)
LCD display screen to monitor cell SOC, voltage, temperature and alarm status
Cell balance function
Metal Case, excellent heat dissipation, more safety
Over charge, over discharge, over temperature, low temperature, over current and short circuit protection
Certificate: UN38.3, MSDS, IEC62133, IEC62619, EN IEC61000-6-1/2/3/4
Easy installation and maintenance free
Max 2 battery packs can be connected in series
