EU Certified
25.6V 50Ah Lithium Battery
Compact and powerful 25.6V 50Ah lithium battery with EU certification, designed for energy storage systems.
25.6V 50Ah Lithium Battery – EU Certified, Compact and Efficient
For compact energy storage, this 25.6V 50Ah Lithium Battery is an excellent choice. Despite its small size, it delivers a 25A continuous discharge current and a reliable 4000-cycle lifespan. With EU Certification, an ABS casing, and IP65 protection, it is built for rugged environments. The battery's Bluetooth feature allows for easy monitoring, and its heating function enhances performance during cold conditions. Certified by UN38.3, MSDS, IEC62619, and ROHS, this battery combines safety, reliability, and efficiency.
| Model | LFP1.28KWH25.6V-P65L2GT40 |
| Battery Type | LiFePO4 |
| Nominal Voltage | 25.6V |
| Nominal Capacity | 50Ah |
| Energy | 1280Wh |
| Continuous Discharge Current | 25A |
| Charge Cut-off Voltage | 28.8V |
| Discharge Cut-off Voltage | 20.8V |
| Maximum Charge Current | 50A |
| Maximum Discharge Current | 75A@30min |
| Peak Discharge Current | 90A@2S |
| Recommend Discharge Current | 25A |
| Work Voltage Range | 20.8V~29.2V |
| Open-circuit Voltage | 25.4V~26.8V |
| Internal Resistance | ≤20mΩ |
| Cycle Life | >4000 times (0.5C charge&discharge 80%DOD @25℃) |
| Number of series/parallel | Max 2 battery packs in series
Max 4 battery packs in parallel |
| Certification | UN38.3 MSDS IEC62619 CE-RED ROHS |
| Charge&Discharge Temperature | Charge: 0℃~+55℃
Discharge: -20℃~+60℃ |
| Storage Temperature Range① | -5℃~+0℃/35℃~+45℃ (≤2 months)
5℃~+35℃（≤3 months,optimum storage temperature) 15℃~+35℃ (≤6 months) |
| Relative Humidity | 60%±20% RH |
| Connect Terminal | M8 |
| Dimension (L x W x H) | 340mm*185mm*219mm |
| Net Weight | 12.2±0.5KG |
| IP Class | IP65 |
| Warranty | 3 years (See warranty agreement for details) |
DATASHEET
EPEVER_DataSheet_LFP1.28KWH25.6V-P65L2GT40
MANUAL
EPEVER_Manual_LFP1.28KWH25.6V-P65L2GT40
Product Highlights
A grade brand new prismatic LiFePO4 cells
Cell balance function
＞4000 cycles @80% DOD(25℃, 0.5C )
IP65 superior safety
Overcharge, over-discharge, over temperature, low temperature, over current and short circuit protection
Certificate: UN38.3, MSDS, IEC62619, CE-RED, ROHS
Easy installation and maintenance-free
Supports series and parallel connection
Charging Heating Technique
Supports Bluetooth communication
