Rack-Mountable
48V 100Ah Lithium Battery
Elevate your solar energy storage game with EPEVER 48V 100Ah Lithium Battery. With over 4000 cycles, advanced safety features, and parallel connectivity for expanded capacity, this battery is perfect for diverse applications like solar battery banks, home battery backups, residential solar setups, RVs, camping, marine, and emergency power systems.
Experience the power of EPEVER's 48V 100Ah Lithium Battery, featuring A-grade prismatic LiFePO4 cells, ensuring enduring performance. Offering over 4000 cycles at 80% DOD, advanced cell balancing, and robust protection against overcharge, over-discharge, overtemperature, low temperature, overcurrent, and short circuits. This battery communicates seamlessly through RS485, CAN, and RS232 interfaces, ideal for scalable energy solutions, supporting the connection of up to 8 battery packs in parallel.
Tailored for diverse applications like solar battery banks, home battery backups, residential solar setups, RVs, camping, marine, and emergency power systems. Renowned for its reliability, high capacity, and efficiency.
Explore the best prices for your home battery needs. Partner with top-tier lithium battery suppliers. Choose EPEVER for a dependable energy solution.
| Model | LFP4.8KWH48V-P20R1 |
| Battery Type | LiFeP04 |
| Nominal Voltage (V) | 48 |
| Nominal Capacity (AH) | 100 |
| Energy (WH) | 4800 |
| Pack Mode | 15S1P |
| Continuous Discharge Current (A) | 50 |
| Charge Cut-off Voltage (V) | 54 |
| Discharge Cut-off Voltage (V) | 39 |
| Max.Charge Current (A) | 50 |
| Max.Discharge Current (A) | 100 |
| Peak Discharge Current (A) | 130@10S |
| Recommend Discharge Current (A) | 50 |
| Recommend Discharge Depth (%) | 80 |
| Cycle Life | ＞4000 cycles (25°C,0.5C ) 80％ DOD |
| Communication | RS485 CAN RS232 |
| Display | LED |
| Charge&Discharge Temperature (°C) | Charge: 0°C~+55°C I Discharge: -20°C~+60°C |
| Optimal Storage Temperature (°C) | 5°C ~ +35°C |
| Recommend Storage Humidity | 20%~80% |
| Terminal | M6 |
| Dimensions (W*H*D) (mm) | 502*482*176 |
| Weight (Kg) | 47±1 |
| Transportation | UN38.3, MSDS, IEC62619, EN IEC61000-6-1/2/3/4 |
| IP Class | IP20 |
DATASHEET
EPEVER_DataSheet_LFP4.8KWH48V-P20R1
MANUAL
EPEVER_Manual_LFP4.8KWH48V-P20R1
Product Highlights
A-grade brand-new prismatic LiFePO4 cells
>4000 cycles @80% DOD(25℃, 0.5C)
Cell balance function
Support RS485, CAN，RS232 communication
Overcharge, over-discharge, over temperature, low temperature, over current, and short circuit protection
Max 8 battery packs can be connected in parallel
