Solid-State
51.2V 212Ah Lithium Battery
The 51.2V 212Ah large-capacity solid-state lithium battery with LCD display offers 5000 cycles, modular design, and IP65 protection for energy storage.
This 51.2V 212Ah stackable solid-state lithium battery features a large-capacity design with an LCD display for monitoring. With 5000 cycles and IP65 protection, it’s built for modular energy storage systems that require scalability and high performance.
| Model | LFP10.85KWH51.2V-P65F2QT50 |
| Battery Type | LiFePO4 |
| Nominal Voltage (V) | 51.2 |
| Nominal Capacity (AH) | 212 |
| Energy (WH) | 10854 |
| Pack Mode | 16S4P |
| Continuous Discharge Current (A) | 100 |
| Charge Cut-off Voltage (V) | 57.6 |
| Discharge Cut-off Voltage (V) | 41.6 |
| Max.Charge Current (A) | 100 |
| Max.Discharge Current (A) | 200 |
| Peak Discharge Current (A) | 240@2S |
| Recommend Discharge Current (A) | 100 |
| Recommend Discharge Depth (%) | 80 |
| Cycle Life | >5000 cycles (25°C, 0.5C) 80% DOD |
| Communication | CAN RS485 RS232 |
| Display | LCD |
| Charge&Discharge Temperature (°C) | Charge: 0°C~+55°C / Discharge: -20°C~+60°C |
| Optimal Storage Temperature (°C) | 5°C ~ +35°C |
| Recommend Storage Humidity | 60%±20% RH |
| Terminal | Quick-connector |
| Dimensions (L*W*H) (mm) | 601*160*885 |
| Weight (Kg) | 93.1±0.5 |
| Certificate | UN38.3, MSDS, IEC62619, ROHS |
| IP Class | IP65 |
DATASHEET
EPEVER_DataSheet_LFP10.85KWH51.2V-P65F2QT50
MANUAL
EPEVER_Manual_LFP10.85KWH51.2V-P65F2QT50
Product Highlights
A grade brand new solid-state LiFePO4 cells
＞5000 cycles @80% DOD (25℃, 0.5C)
Overcharge, over-discharge, over temperature, low temperature, over current, and short circuit protection
Compatible with most inverters
Stackable
Cell balance function
Max.8 battery packs can be connected in parallel
Certificate: UN38.3, MSDS, IEC62619, ROHS
