Tracer BP Series(10~30A) IOT MPPT Charge Controller
With RS485 communication port and IP68 waterproof design.
Tracer-BP series adopts advanced MPPT (Maximum Power Point Tracking) charging methods which will results in up to 30% charging efficiency increase compared with the PWM charge controllers. The RS485 interface with standard MODBUS communication protocol and 5V,150mA power supply makes it easy for the customer to expand the application. With the accessories like MT50, WiFi module, Bluetooth adapter, IoT module, users can realize remote monitoring and controlling the solar system via app and cloud platform.
| Model | Tracer2606BP | Tracer3906BP | Tracer5206BP | Tracer2610BP | Tracer3910BP | Tracer5210BP | Tracer7810BP |
| Nominal system voltage | 12/24VDC Auto | ||||||
| Battery type | Lead-acid (Sealed/Gel/Flooded)/Lithium (LiFePO4/Li(NiCoMn)O2)/User | ||||||
| Battery input voltage range | 8.5๏ฝ32VDC | ||||||
| Rated charge current | 10A | 15A | 20A | 10A | 15A | 20A | 30A |
| Rated discharge current | 10A | 15A | 20A | 10A | 15A | 20A | 30A |
| Rated charge power | ย ย ย 130W/12Vย ย ย ย 260W/24V | 200W/12V 400W/24V |
ย ย 260W/12Vย ย ย 520W/24V |
ย ย 130W/12Vย ย ย 260W/24V | 200W/12V 400W/24V |
ย 260W/12Vย ย 520W/24V | ย ย 390W/12Vย ย ย 780W/24V |
| Max. conversion efficiency | โค98% | ||||||
| Tracking efficiency | โฅ99% | ||||||
| Max. PV open circuit voltage | 60V( at minimum operating environment temperature ๏ผ 46V( at 25โ environment temperature ) |
100V( at minimum operating environment temperature ๏ผ 92V( at 25โ environment temperature ) |
|||||
| MPP voltage range | (Battery voltage+2V)๏ฝ36V | (Battery voltage+2V)๏ฝ36V | (Battery voltage+2V)๏ฝ36V | (Battery voltage+2V)๏ฝ72V | (Battery voltage+2V)๏ฝ72V | (Battery voltage+2V)๏ฝ72V | (Battery voltage+2V)๏ฝ72V |
| Equalization voltage | Sealed:14.6V,Flooded:14.8V,User-defined:9-17V | ||||||
| Boost voltage | Gel:14.2V,Sealed:14.4V,Flooded:14.6V,User-defined:9-17V | ||||||
| Float voltage | Gel/Sealed/Flooded:13.8V,User-defined:9-17V | ||||||
| Low voltage reconnect voltage | Gel/Sealed/Flooded:12.6V,User-defined:9-17V | ||||||
| Low voltage disconnect voltage | Gel/Sealed/Flooded:11.1V,User-defined:9-17V | ||||||
| Self-consumption | ย ย โค13mA(12V)๏ผโค11.5mA(24V) | ||||||
| Temperature compensation( for lead-acid battery) | -3mV/โ/2V(default) | ||||||
| Enclosure | IP68 | ||||||
| Communication interface | RS485๏ผ waterproof๏ผ | ||||||
| Operating temperature range | -40โ๏ฝ+60โ | -40โ๏ฝ+60โ | -40โ๏ฝ+60โ | -40โ๏ฝ+60โ | -40โ๏ฝ+60โ | -40โ๏ฝ+60โ | -40โ๏ฝ+50โ |
| Dimensions(LxWxH)(mm) | 124ร89ร30 | 150ร93.5ร32.7 | 153ร105ร52.1 | 124ร89ร30 | 150ร93.5ร32.7 | 153ร105ร52.1 | 153.3ร105ร52.1 |
| Net weight | 0.54kg | 0.74kg | 1.20kg | 0.54kg | 0.74kg | 1.20kg | 1.26kg |
| 1. The controller can't automatically identify system voltage if lithium batteries were connected. | |||||||
| 2. The voltage point is for a 12V system, please *2 in the 24V system. | |||||||
Datasheet
EPEVER-Datasheet-Tracer-BP
Manual
Tracer-BP-Manual-EN-V3.5
Certificates
Certificate EN LVD Tracer-BP
Certificates
Certificate IEC Tracer-BP
Certificates
Certificate EMC Tracer-BP
Certificates
Certificates ROHS Tracer-BP
Manuale MPPT Tracer BP
Manuale MPPT Tracer BP
Product Highlights
MPPT๏ผmaximum power point tracking๏ผcharging
Support lead-acid and lithium-ion batteries
Lithium battery self-activating function
Multi load control mode
Extensive electronic protetions
RS 485 communication, support IOT monitoring
IP68 Ingress protection(1.5 meters, 72h)
Tracer-BP can work with LED light, but the condition is that the LED lights must have a built-in LED driver.
